Specifications
Engine
-
- MODEL
- D24
-
- RATED FLYWHEEL POWER (GROSS)
- 48.5 hp @ 2100 rpm (SAE-J1995)
-
- RATED HORSE POWER (NET)
- 65 hp @ 2100 rpm
-
- MAX. TORQUE (NET)
- 284 lbf·ft @ 1600 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NAME
- 2.4L Turbocharged Engine w/ 4-Cylinders
-
- ENGINE NUMBER OF CYLINDERS
- 4
-
- ENGINE DISPLACEMENT
- 146 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 0.67 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 39.36 gal/min
-
- MAIN PUMP: QUANTITY
- 1
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 1
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 5
-
- TRACK LENGTH
- 5′ 10″
-
- TRACK LINK: TRACK GAUGE
- 5′ 10″
-
- GROUND CLEARANCE
- 11.6″
-
- GROUND PRESSURE
- 3.98 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 2618 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.9 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 14550 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.68 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 2.92 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 58 °
Weights
-
- OPERATING WEIGHT
- 21025 lb
-
- STANDARD BOOM LENGTH
- 11′ 1″
-
- STANDARD ARM LENGTH
- 5′ 6″
-
- STANDARD BUCKET SIZE
- 0.37 yd³
-
- SHOE WIDTH
- 1′ 5″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 8′ 8″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 11′ 2″
-
- SHIPPING WIDTH (STANDARD)
- 7′ 4″
-
- OVERALL HEIGHT OVER CAB
- 8′ 8″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 22′ 5″
-
- MAX DIGGING HEIGHT
- 21′ 11″
-
- MAX DIGGING DEPTH
- 13′ 5″
-
- MAX LOADING HEIGHT
- 15′ 5″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 9824 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 14770 lbf
-
- ARM DIGGING FORCE – NORMAL
- 9479 lbf
Refill Capacities
-
- FUEL TANK
- 42.27 gal
-
- HYDRAULIC SYSTEM
- 36.98 gal
-
- ENGINE COOLANT
- 2.64 gal
-
- ENGINE OIL
- 2.27 gal
-
- HYDRAULIC TANK
- 24.83 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 99 dBA
-
- NOISE LEVEL: OPERATOR
- 75 dBA
