DX50Z-7
Call for Pricing
Price
Request a Quote
Trade Value
Print
Call Us
Make:
Develon Equipment
Model:
DX50Z-7
Category:
Develon Equipment, Mini Excavator, New
overview
Specifications
Engine
MODEL
D18
RATED FLYWHEEL POWER (GROSS)
48.8 hp @ 2200 rpm
RATED HORSE POWER (NET)
48.8 hp @ 2200 rpm
MAX. TORQUE (NET)
133 lbf·ft @ 1600 rpm
ENGINE EMISSIONS TIER (EPA)
Tier 4
ENGINE AFTER TREATMENT
DOC Only
ENGINE MAKE
DEVELON
ENGINE NAME
D18 Turbo
ENGINE NUMBER OF CYLINDERS
3
ENGINE DISPLACEMENT
146 in³
Hydraulic System
MAIN PUMP: DISPLACEMENT
3.84 in³/rev
MAIN PUMP: MAX. FLOW RATE (EACH)
36.61 gal/min
MAIN PUMP: QUANTITY
1
MAIN PUMP: MAIN RELIEF PRESSURE
4206 psi
Undercarriage
UPPER ROLLERS: QUANTITY PER SIDE
1
LOWER ROLLERS: QUANTITY PER SIDE
4
TRACK LENGTH
8′ 2″
TRACK LINK: TRACK GAUGE
5′ 2″
GROUND CLEARANCE
2′ 1″
GROUND PRESSURE
4.41 psi
Swing Mechanism
SWING PERFORMANCE: MAX SWING TORQUE
9982 lbf·ft
SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
9.8 rpm
Travel System/Drive Mechanism
TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
1153270 lbf
TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
1.62 mph
TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
2.73 mph
TRAVEL PERFORMANCE: GRADEABILITY
35 ° @ 70 %
Weights
OPERATING WEIGHT
11971 lb
STANDARD BOOM LENGTH
8′ 10″
STANDARD ARM LENGTH
4′ 9″
STANDARD BUCKET SIZE
0.21 yd³
SHOE WIDTH
1′ 3″
Dimensions
SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
8′ 4″
SHIPPING LENGTH (WITHOUT ATTACHMENT)
17′ 9″
SHIPPING WIDTH (STANDARD)
6′ 5″
OVERALL HEIGHT OVER CAB
8′ 4″
Working Range
MAX DIGGING REACH (GROUND)
19′ 0″
MAX DIGGING HEIGHT
18′ 3″
MAX DIGGING DEPTH
11′ 5″
MAX LOADING HEIGHT
12′ 6″
Digging Force (ISO)
ARM DIGGING FORCE – PRESSURE UP
528.3 lbf
BUCKET DIGGING FORCE – PRESSURE UP
775.59 lbf
Refill Capacities
FUEL TANK
20.61 gal
HYDRAULIC SYSTEM
27.74 gal
ENGINE COOLANT
2.85 gal
ENGINE OIL
2.43 gal
HYDRAULIC TANK
12.68 gal
Environment
NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
97 dBA
NOISE LEVEL: OPERATOR
78 dBA
