Specifications
Engine
-
- MODEL
- DN1.7
-
- RATED FLYWHEEL POWER (GROSS)
- 24.7 hp @ 2200 rpm
-
- RATED HORSE POWER (NET)
- 24.7 hp @ 2200 rpm
-
- MAX. TORQUE (NET)
- 72 lbf·ft @ 1600 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- Muffler Only
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NUMBER OF CYLINDERS
- 3
-
- ENGINE DISPLACEMENT
- 101 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 2.05 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 7.61 gal/min
-
- MAIN PUMP: QUANTITY
- 2
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3408 psi
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 1
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 3
-
- TRACK LENGTH
- 6′ 11″
-
- TRACK LINK: TRACK GAUGE
- 4′ 1″
-
- GROUND CLEARANCE
- 8.5″
-
- GROUND PRESSURE
- 3.98 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 4025 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.3 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 703652 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.49 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 2.61 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 6173 lb
-
- STANDARD BOOM LENGTH
- 8′ 3″
-
- STANDARD ARM LENGTH
- 3′ 7″
-
- STANDARD BUCKET SIZE
- 0.1 yd³
-
- SHOE WIDTH
- 11.8″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- in
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 13′ 9″
-
- SHIPPING WIDTH (STANDARD)
- 5′ 1″
-
- OVERALL HEIGHT OVER CAB
- 8′ 0″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 14′ 9″
-
- MAX DIGGING HEIGHT
- 14′ 4″
-
- MAX DIGGING DEPTH
- 8′ 8″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 292.25 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 499.08 lbf
Refill Capacities
-
- FUEL TANK
- 12.42 gal
-
- ENGINE COOLANT
- 1.27 gal
-
- ENGINE OIL
- 1.53 gal
-
- HYDRAULIC TANK
- 12.94 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 97 dBA
-
- NOISE LEVEL: OPERATOR
- 78 dBA
