Specifications
Engine
-
- MODEL
- D18
-
- RATED FLYWHEEL POWER (GROSS)
- 48.8 hp @ 2200 rpm
-
- RATED HORSE POWER (NET)
- 48.8 hp @ 2200 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC Only
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NAME
- D18 Turbo
-
- ENGINE NUMBER OF CYLINDERS
- 3
-
- ENGINE DISPLACEMENT
- 146 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 3.84 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 36.61 gal/min
-
- MAIN PUMP: QUANTITY
- 1
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 1
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 4
-
- TRACK LENGTH
- 8′ 2″
-
- TRACK LINK: TRACK GAUGE
- 5′ 2″
-
- GROUND CLEARANCE
- 2′ 1″
-
- GROUND PRESSURE
- 4.69 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 9982 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.8 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 10004 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.62 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 2.73 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 11963 lb
-
- STANDARD BOOM LENGTH
- 8′ 10″
-
- STANDARD ARM LENGTH
- 5′ 3″
-
- STANDARD BUCKET SIZE
- 0.21 yd³
-
- SHOE WIDTH
- 1′ 3″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 8′ 4″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 17′ 10″
-
- SHIPPING WIDTH (STANDARD)
- 6′ 5″
-
- OVERALL HEIGHT OVER CAB
- 8′ 4″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 19′ 6″
-
- MAX DIGGING HEIGHT
- 18′ 7″
-
- MAX DIGGING DEPTH
- 11′ 10″
-
- MAX LOADING HEIGHT
- 12′ 10″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 627.22 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 995.9 lbf
Refill Capacities
-
- FUEL TANK
- 20.61 gal
-
- HYDRAULIC SYSTEM
- 27.74 gal
-
- ENGINE COOLANT
- 2.85 gal
-
- ENGINE OIL
- 2.43 gal
-
- HYDRAULIC TANK
- 12.68 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 97 dBA
-
- NOISE LEVEL: OPERATOR
- 78 dBA
