Specifications
Engine
-
- MODEL
- DC13
-
- RATED FLYWHEEL POWER (GROSS)
- 394 hp @ 1800 rpm (SAE-J1995)
-
- RATED HORSE POWER (NET)
- 394 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 1591 lbf·ft @ 1200 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC + SCR
-
- ENGINE MAKE
- Scania
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 775 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 6.83 in³/rev
-
- SYSTEM PRESSURE: WORK
- 3626 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 62 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3626 psi
Undercarriage
-
- TIRE SIZE
- 875 65R29
-
- TREAD WIDTH
- 7′ 11″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 30 ° @ 58 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 72312 lb
Weights
-
- OPERATING WEIGHT
- 79572 lb
Dimensions
-
- BUCKET CAPACITY
- 8.4 yd³
-
- BUCKET WIDTH
- 11′ 2″
-
- HINGE PIN HEIGHT
- 15′ 8″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 5′ 4″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 10′ 5″
-
- OVERALL HEIGHT
- 12′ 7″
-
- OVERALL LENGTH
- 32′ 11″
-
- WHEEL BASE
- 12′ 1″
-
- GROUND CLEARANCE
- 1′ 7″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 25′ 0″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 60550 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 53462 lb
-
- BREAKOUT FORCE
- 64071 lbf
-
- REAR AXLE OSCILLATION
- 20 °
-
- DIGGING DEPTH
- 3.0″
Transmission
-
- SPEEDS FWD
- 5
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 3.91 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 17.46 mph
-
- FINAL DRIVE
- Planetary
-
- DIFFERENTIAL TYPE
- Hydraulic Locking
Refill Capacities
-
- FUEL TANK
- 116.5 gal
-
- COOLING SYSTEM
- 14.27 gal
-
- HYDRAULIC SYSTEM
- 63.93 gal
-
- HYDRAULIC TANK
- 63.93 gal
-
- DEF / AD BLUE TANK
- 15.85 gal
