Specifications
Engine
-
- MODEL
- DL06P
-
- RATED FLYWHEEL POWER (GROSS)
- 171.7 hp @ 2100 rpm
-
- RATED HORSE POWER (NET)
- 171.7 hp @ 2100 rpm
-
- MAX. TORQUE (NET)
- 593 lbf·ft @ 1400 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC+SCR with DEF
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 360 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 5.37 in³/rev
-
- SYSTEM PRESSURE: WORK
- 3843 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 48.8 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3843 psi
-
- TOTAL CYCLE TIME
- 10.8 s (±0.3 s)
Undercarriage
-
- TIRE SIZE
- 20.5-R25 (L3)
-
- TREAD WIDTH
- 6′ 8″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 30 ° @ 58 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 26455 lb
Weights
-
- OPERATING WEIGHT
- 31605 lb
Dimensions
-
- BUCKET CAPACITY
- 3.10 yd³
-
- BUCKET WIDTH
- 8′ 11″
-
- HINGE PIN HEIGHT
- 12′ 10″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 4′ 3″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 9′ 0″
-
- OVERALL HEIGHT
- 10′ 9″
-
- OVERALL LENGTH
- 25′ 7″
-
- WHEEL BASE
- 9′ 10″
-
- GROUND CLEARANCE
- 1′ 5″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 20′ 2″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 20470 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 18078 lb
-
- BREAKOUT FORCE
- 22930 lbf
-
- REAR AXLE OSCILLATION
- 22 °
-
- DIGGING DEPTH
- 3.0″
Transmission
-
- SPEEDS FWD
- 4
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 4.1 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 23.5 mph
-
- FINAL DRIVE
- Planetary-Outboard
-
- DIFFERENTIAL TYPE
- Limited Slip
Refill Capacities
-
- FUEL TANK
- 62.08 gal
-
- COOLING SYSTEM
- 8.29 gal
-
- HYDRAULIC SYSTEM
- 39.63 gal
-
- HYDRAULIC TANK
- 31.7 gal
-
- DEF / AD BLUE TANK
- 8.32 gal
