Specifications
Engine
-
- MODEL
- 1204F
-
- RATED FLYWHEEL POWER (GROSS)
- 142.1 hp @ 2200 rpm
-
- RATED HORSE POWER (NET)
- 142.1 hp @ 2200 rpm
-
- MAX. TORQUE (NET)
- 413 lbf·ft @ 1400 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- CEGR+DOC+SCR with DEF
-
- ENGINE MAKE
- Perkins
-
- ENGINE NAME
- DL200TC-5
-
- ENGINE NUMBER OF CYLINDERS
- 4
-
- ENGINE DISPLACEMENT
- 269 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 4.51 in³/rev
-
- SYSTEM PRESSURE: WORK
- 2901 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 40.9 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3843 psi
-
- TOTAL CYCLE TIME
- 11.9 s (±0.3 s)
Undercarriage
-
- TIRE SIZE
- 20.5-R25 (L3)
-
- TREAD WIDTH
- 6′ 4″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 30 ° @ 58 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 17600 lb
Weights
-
- OPERATING WEIGHT
- 26868 lb
Dimensions
-
- BUCKET CAPACITY
- 2.62 yd³
-
- BUCKET WIDTH
- 8′ 4″
-
- HINGE PIN HEIGHT
- 12′ 6″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 3′ 1″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 8′ 10″
-
- OVERALL HEIGHT
- 10′ 10″
-
- OVERALL LENGTH
- 24′ 8″
-
- WHEEL BASE
- 9′ 9″
-
- GROUND CLEARANCE
- 1′ 5″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 18′ 9″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 18827 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 16623 lb
-
- BREAKOUT FORCE
- 21357 lbf
-
- REAR AXLE OSCILLATION
- 22 °
-
- DIGGING DEPTH
- 3.0″
Transmission
-
- SPEEDS FWD
- 4
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 8.08 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 23.61 mph
-
- FINAL DRIVE
- Planetary-Outboard
-
- DIFFERENTIAL TYPE
- Limited Slip
Refill Capacities
-
- FUEL TANK
- 48.08 gal
-
- COOLING SYSTEM
- 8.06 gal
-
- HYDRAULIC SYSTEM
- 34.34 gal
-
- HYDRAULIC TANK
- 34.08 gal
-
- DEF / AD BLUE TANK
- 5.02 gal
