Specifications
Engine
-
- MODEL
- DL06
-
- RATED FLYWHEEL POWER (GROSS)
- 171.7 hp @ 2100 rpm (SAE-J1995)
-
- RATED HORSE POWER (NET)
- 171.7 hp @ 2100 rpm
-
- MAX. TORQUE (NET)
- 593 lbf·ft @ 1400 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- CEGR+DOC+SCR with DEF
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 359 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 4.52 in³/rev
-
- SYSTEM PRESSURE: WORK
- 3844 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 40.95 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3843 psi
-
- TOTAL CYCLE TIME
- 11.4 s (±3 s)
Undercarriage
-
- TIRE SIZE
- 20.5R25, L3
-
- TREAD WIDTH
- 6′ 8″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 30 ° @ 58 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 29101 lb
Weights
-
- OPERATING WEIGHT
- 30527 lb
Dimensions
-
- BUCKET CAPACITY
- 3.27 yd³
-
- BUCKET WIDTH
- 8′ 11″
-
- HINGE PIN HEIGHT
- 12′ 7″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 3′ 6″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 9′ 2″
-
- OVERALL HEIGHT
- 10′ 10″
-
- OVERALL LENGTH
- 24′ 6″
-
- WHEEL BASE
- 10′ 0″
-
- GROUND CLEARANCE
- 1′ 5″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 19′ 10″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 23973 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 21134 lb
-
- BREAKOUT FORCE
- 23987 lbf
-
- REAR AXLE OSCILLATION
- 22 °
-
- DIGGING DEPTH
- 2.0″
Transmission
-
- SPEEDS FWD
- 4
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 3.98 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 23.3 mph
-
- FINAL DRIVE
- Planetary
-
- DIFFERENTIAL TYPE
- Limited Slip
Refill Capacities
-
- FUEL TANK
- 62.08 gal
-
- COOLING SYSTEM
- 8.98 gal
-
- HYDRAULIC SYSTEM
- 31.7 gal
-
- HYDRAULIC TANK
- 22.45 gal
-
- DEF / AD BLUE TANK
- 7.93 gal
