Specifications
Engine
-
- MODEL
- DC13
-
- RATED FLYWHEEL POWER (GROSS)
- 380 hp @ 1800 rpm (SAE-J1995)
-
- RATED HORSE POWER (NET)
- 380 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 1302 lbf·ft @ 1300 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC + SCR
-
- ENGINE MAKE
- Scania
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 452 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 6.1 in³/rev
-
- SYSTEM PRESSURE: WORK
- 3626 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 55.5 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3626 psi
Undercarriage
-
- TIRE SIZE
- 29.5R25 (L3)
-
- TREAD WIDTH
- 7′ 11″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 58 ° @ 30 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 72091 lb
Weights
-
- OPERATING WEIGHT
- 70599 lb
Dimensions
-
- BUCKET CAPACITY
- 6.8 yd³
-
- BUCKET WIDTH
- 11′ 2″
-
- HINGE PIN HEIGHT
- 15′ 7″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 4′ 4″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 11′ 3″
-
- OVERALL HEIGHT
- 12′ 7″
-
- OVERALL LENGTH
- 32′ 5″
-
- WHEEL BASE
- 12′ 1″
-
- GROUND CLEARANCE
- 1′ 6″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 24′ 6″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 53273 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 47042 lb
-
- BREAKOUT FORCE
- 56202 lbf
-
- REAR AXLE OSCILLATION
- 20 °
-
- DIGGING DEPTH
- 3.0″
Transmission
-
- SPEEDS FWD
- 4
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 3.79 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 23.18 mph
-
- FINAL DRIVE
- Planetary
-
- DIFFERENTIAL TYPE
- Hydraulic Locking
Refill Capacities
-
- FUEL TANK
- 116.5 gal
-
- COOLING SYSTEM
- 14.27 gal
-
- HYDRAULIC SYSTEM
- 63.93 gal
-
- HYDRAULIC TANK
- 63.93 gal
-
- DEF / AD BLUE TANK
- 15.85 gal
