Specifications
Engine
-
- MODEL
- DL08
-
- RATED FLYWHEEL POWER (GROSS)
- 271 hp @ 1800 rpm
-
- RATED HORSE POWER (NET)
- 271 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 940 lbf·ft @ 1300 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- SCR + DOC
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 466 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 4.52 in³/rev
-
- SYSTEM PRESSURE: WORK
- 3844 psi
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 41 gal/min
-
- MAIN PUMP: QUANTITY
- 1
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 3844 psi
Undercarriage
-
- TIRE SIZE
- 23.5 R25
-
- TREAD WIDTH
- 7′ 0″
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 27 ° @ 51 %
-
- TRAVELING PERFORMANCE: MAX. TRACTIVE EFFORT
- 43872 lb
Weights
-
- OPERATING WEIGHT
- 44919 lb
Dimensions
-
- BUCKET CAPACITY
- 4.84 yd³
-
- BUCKET WIDTH
- 9′ 10″
-
- HINGE PIN HEIGHT
- 13′ 8″
-
- DUMP REACH AT 45° (FULLY RAISED)
- 4′ 0″
-
- DUMP HEIGHT AT 45° (FULLY RAISED)
- 9′ 11″
-
- OVERALL HEIGHT
- 11′ 6″
-
- OVERALL LENGTH
- 27′ 10″
-
- WHEEL BASE
- 10′ 9″
-
- GROUND CLEARANCE
- 1′ 3″
-
- EXTERNAL TURNING RADIUS AT BUCKET EDGE
- 21′ 7″
-
- STATIC TIPPING LOAD (STRAIGHT)
- 36198 lb
-
- STATIC TIPPING LOAD (FULL TURN)
- 31963 lb
-
- BREAKOUT FORCE
- 36194 lbf
-
- REAR AXLE OSCILLATION
- 24 °
-
- DIGGING DEPTH
- 3.0″
Transmission
-
- SPEEDS FWD
- 4
-
- SPEEDS REV
- 3
-
- TRAVEL SPEED FORWARD – 1ST GEAR
- 3.91 mph
-
- TRAVEL SPEED FORWARD – 4TH GEAR
- 22.37 mph
-
- FINAL DRIVE
- Planetary
-
- DIFFERENTIAL TYPE
- Limited Slip
Refill Capacities
-
- FUEL TANK
- 76.87 gal
-
- COOLING SYSTEM
- 11.89 gal
-
- HYDRAULIC SYSTEM
- 47.55 gal
-
- HYDRAULIC TANK
- 30.91 gal
-
- DEF / AD BLUE TANK
- 16.38 gal
