Specifications
Engine
-
- MODEL
- Perkins 2506J
-
- RATED FLYWHEEL POWER (GROSS)
- 539.1 hp @ 2100 rpm
-
- RATED HORSE POWER (NET)
- 528.6 hp @ 2100 rpm
-
- MAX. TORQUE (NET)
- 1821 lbf·ft @ 1400 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC+DPF+SCR with DEF
-
- ENGINE MAKE
- Perkins
-
- ENGINE NAME
- Perkins 2506J
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 928 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 17.09 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 133.14 gal/min
-
- MAIN PUMP: QUANTITY
- 2
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 5076 psi
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 3
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 8
-
- TRACK LENGTH
- 19′ 6″
-
- TRACK LINK: TRACK GAUGE
- 10′ 11″
-
- GROUND CLEARANCE
- 2′ 8″
-
- GROUND PRESSURE
- 12.66 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 228563 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 7.4 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 15893992 lbf @ 100
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.86 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 3.04 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 181000 lb
-
- STANDARD BOOM LENGTH
- 25′ 3″
-
- STANDARD ARM LENGTH
- 11′ 7″
-
- SHOE WIDTH
- 2′ 11″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 15′ 11″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 43′ 2″
-
- SHIPPING WIDTH (STANDARD)
- 12′ 6″
-
- OVERALL HEIGHT OVER CAB
- 11′ 7″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 42′ 5″
-
- MAX DIGGING HEIGHT
- 39′ 4″
-
- MAX DIGGING DEPTH
- 27′ 5″
-
- MAX LOADING HEIGHT
- 27′ 5″
Digging Force (ISO)
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 8678 lbf
-
- ARM DIGGING FORCE – NORMAL
- 6542 lbf
Refill Capacities
-
- FUEL TANK
- 232.47 gal
-
- ENGINE COOLANT
- 22.8 gal
-
- ENGINE OIL
- 15.85 gal
-
- HYDRAULIC TANK
- 114.91 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 109 dBA
-
- NOISE LEVEL: OPERATOR
- 71 dBA
