Specifications
Engine
-
- MODEL
- G2
-
- RATED FLYWHEEL POWER (GROSS)
- 115.3 hp @ 2000 rpm
-
- RATED HORSE POWER (NET)
- 109.4 hp @ 2000 rpm
-
- MAX. TORQUE (NET)
- 339 lbf·ft @ 1400 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- DOC+SCR+ with DEF
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NAME
- DEVELON D34
-
- ENGINE NUMBER OF CYLINDERS
- 4
-
- ENGINE DISPLACEMENT
- 208 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 3.48 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 30.12 gal/min
-
- MAIN PUMP: QUANTITY
- 2
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 1
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 7
-
- TRACK LENGTH
- 12′ 3″
-
- TRACK LINK: TRACK GAUGE
- 6′ 6″
-
- GROUND CLEARANCE
- 1′ 3″
-
- GROUND PRESSURE
- 5.55 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 35355 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 10.13 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 33497 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.68 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 2.86 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 33951 lb
-
- STANDARD BOOM LENGTH
- 15′ 1″
-
- STANDARD ARM LENGTH
- 9′ 10″
-
- STANDARD BUCKET SIZE
- 0.67 yd³
-
- SHOE WIDTH
- 1′ 11″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 10′ 3″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 24′ 0″
-
- SHIPPING WIDTH (STANDARD)
- 8′ 5″
-
- OVERALL HEIGHT OVER CAB
- 9′ 3″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 27′ 11″
-
- MAX DIGGING HEIGHT
- 31′ 0″
-
- MAX DIGGING DEPTH
- 19′ 7″
-
- MAX LOADING HEIGHT
- 23′ 2″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 13219 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 24504 lbf
-
- ARM DIGGING FORCE – NORMAL
- 22931 lbf
Refill Capacities
-
- FUEL TANK
- 54.95 gal
-
- HYDRAULIC SYSTEM
- 55.48 gal
-
- ENGINE COOLANT
- 6.74 gal
-
- ENGINE OIL
- 3.33 gal
-
- HYDRAULIC TANK
- 33.81 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 98 dBA
-
- NOISE LEVEL: OPERATOR
- 72 dBA
