Specifications
Engine
-
- MODEL
- DC13
-
- RATED FLYWHEEL POWER (GROSS)
- 394.3 hp @ 1800 rpm
-
- RATED HORSE POWER (NET)
- 387.6 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 1373 lbf·ft @ 900 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- CEGR+DOC+SCR with DEF
-
- ENGINE MAKE
- Scania
-
- ENGINE NAME
- Scania DC13
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 775 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 13.73 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 103.03 gal/min
-
- MAIN PUMP: QUANTITY
- 2
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 4700 psi
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 2
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 9
-
- TRACK LENGTH
- 17′ 10″
-
- TRACK LINK: TRACK GAUGE
- 12′ 3″
-
- GROUND CLEARANCE
- 2′ 4″
-
- GROUND PRESSURE
- 733.92 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 145601 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 100714 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 1.99 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 3.48 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 112215 lb
-
- STANDARD BOOM LENGTH
- 23′ 3″
-
- STANDARD ARM LENGTH
- 10′ 11″
-
- STANDARD BUCKET SIZE
- 3.14 yd³
-
- SHOE WIDTH
- 2′ 11″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 12′ 1″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 40′ 1″
-
- SHIPPING WIDTH (STANDARD)
- 10′ 9″
-
- OVERALL HEIGHT OVER CAB
- 10′ 11″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 38′ 11″
-
- MAX DIGGING HEIGHT
- 36′ 3″
-
- MAX DIGGING DEPTH
- 25′ 6″
-
- MAX LOADING HEIGHT
- 25′ 9″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 48784 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 60024 lbf
-
- ARM DIGGING FORCE – NORMAL
- 45861 lbf
Refill Capacities
-
- FUEL TANK
- 165.37 gal
-
- HYDRAULIC SYSTEM
- 103.03 gal
-
- ENGINE COOLANT
- 13.87 gal
-
- ENGINE OIL
- 11.89 gal
-
- HYDRAULIC TANK
- 70.01 gal
