Specifications
Engine
-
- MODEL
- DC13
-
- RATED FLYWHEEL POWER (GROSS)
- 344.6 hp @ 1800 rpm
-
- RATED HORSE POWER (NET)
- 337.9 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 1143 lbf·ft @ 800 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- CEGR + DOC + SCR
-
- ENGINE MAKE
- Scania
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 775 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 11.29 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 87.97 gal/min
-
- MAIN PUMP: QUANTITY
- 2
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 4700 psi
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 2
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 8
-
- TRACK LENGTH
- 17′ 0″
-
- TRACK LINK: TRACK GAUGE
- 9′ 0″
-
- GROUND CLEARANCE
- 1′ 11″
-
- GROUND PRESSURE
- 7.82 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 95837 lbf·ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.4 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 95769 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 2.05 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 3.36 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 97718 lb
-
- STANDARD BOOM LENGTH
- 21′ 11″
-
- STANDARD ARM LENGTH
- 10′ 7″
-
- STANDARD BUCKET SIZE
- 2.51 yd³
-
- SHOE WIDTH
- 2′ 11″
Dimensions
-
- SHIPPING HEIGHT – HOSE (WITH ATTACHMENT)
- 11′ 4″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 38′ 6″
-
- SHIPPING WIDTH (STANDARD)
- 12′ 11″
-
- OVERALL HEIGHT OVER CAB
- 10′ 6″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 36′ 9″
-
- MAX DIGGING HEIGHT
- 34′ 9″
-
- MAX DIGGING DEPTH
- 25′ 0″
-
- MAX LOADING HEIGHT
- 10′ 1″
Digging Force (ISO)
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 55078 lbf
-
- ARM DIGGING FORCE – NORMAL
- 41365 lbf
Refill Capacities
-
- FUEL TANK
- 166.43 gal
-
- HYDRAULIC SYSTEM
- 97.74 gal
-
- ENGINE COOLANT
- 13.95 gal
-
- ENGINE OIL
- 11.89 gal
-
- HYDRAULIC TANK
- 70.01 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 105 dBA
-
- NOISE LEVEL: OPERATOR
- 71 dBA
Lift Capacity
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT ABOVE GROUND
- 45270 lb @ 15 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – GROUND LEVEL
- 46130 lb @ 15 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT BELOW GROUND
- 46340 lb @ 15 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 3M ABOVE GROUND
- 45261 lb @ 14.76 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 3M BELOW GROUND
- 46341 lb @ 14.76 ft
