Specifications
Engine
-
- MODEL
- DL08
-
- RATED FLYWHEEL POWER (GROSS)
- 271 hp @ 1800 rpm
-
- RATED HORSE POWER (NET)
- 271 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 940 lbf·ft @ 1300 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE MAKE
- DEVELON
-
- ENGINE NAME
- DEVELON DL08-LEE04
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 466 in³
Undercarriage
-
- BOTTOM ROLLERS: QUANTITY PER SIDE
- 2
-
- TRACK LENGTH
- 16′ 3″
-
- TRACK LINK: TRACK GAUGE
- 9′ 0″
-
- GROUND PRESSURE
- 6.9 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING TORQUE
- 90,348 lbf.ft
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.8 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRACTION FORCE (HIGHEST VALUE)
- 83,335 lbf
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 2.0 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 3.2 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 °
Weights
-
- OPERATING WEIGHT
- 79,807 lb
-
- STANDARD BOOM LENGTH
- 246′ 0″
-
- STANDARD ARM LENGTH
- 122′ 0″
-
- STANDARD BUCKET SIZE
- 1.66 yd³
-
- SHOE WIDTH
- 2′ 9″
Dimensions
-
- SHIPPING HEIGHT – BOOM
- 11′ 8″
-
- SHIPPING HEIGHT – BOOM
- 11′ 3″
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 32′ 9″
-
- SHIPPING WIDTH (STANDARD)
- 11′ 10″
-
- OVERALL HEIGHT OVER CAB
- 10′ 6″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 34′ 10″
-
- MAX DIGGING DEPTH
- 22′ 10″
-
- MAX LOADING HEIGHT
- 26′ 6″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 35,055 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 47,400 lbf
-
- ARM DIGGING FORCE – NORMAL
- 33,069 lbf
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 97 dBA
-
- NOISE LEVEL: OPERATOR
- 73 dBA
Lift Capacity
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT ABOVE GROUND
- 24,670 lb 20 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT ABOVE GROUND – LB
- 24,670 lb
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT ABOVE GROUND – FT
- 20′ 0″
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – GROUND LEVEL
- 26,420 lb 20 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – GROUND LEVEL – LB
- 26,420 lb
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – GROUND LEVEL – FT
- 20′ 0″
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT BELOW GROUND
- 24,680 lb 20 ft
-
- LIFTING CAPACITY OVER FRONT @ HORIZONTAL DISTANCE – 10 FT BELOW GROUND – LB
- 24,680 lb
