Specifications
Engine
-
- MODEL
- DL08
-
- RATED FLYWHEEL POWER (GROSS)
- 285.6 hp @ 1800 rpm
-
- RATED HORSE POWER (NET)
- 280.3 hp @ 1800 rpm
-
- MAX. TORQUE (NET)
- 940 lbf·ft @ 1300 rpm
-
- ENGINE EMISSIONS TIER (EPA)
- Tier 4
-
- ENGINE AFTER TREATMENT
- CEGR+DOC+SCR with DEF
-
- ENGINE MAKE
- Doosan
-
- ENGINE NAME
- DL08
-
- ENGINE NUMBER OF CYLINDERS
- 6
-
- ENGINE DISPLACEMENT
- 466 in³
Hydraulic System
-
- MAIN PUMP: DISPLACEMENT
- 12.2 in³/rev
-
- MAIN PUMP: MAX. FLOW RATE (EACH)
- 92.46 gal/min
-
- MAIN PUMP: QUANTITY
- 2
-
- MAIN PUMP: MAIN RELIEF PRESSURE
- 5076 psi
Undercarriage
-
- UPPER ROLLERS: QUANTITY PER SIDE
- 2
-
- LOWER ROLLERS: QUANTITY PER SIDE
- 9
-
- TRACK LENGTH
- 16′ 3″
-
- GROUND CLEARANCE
- 1′ 6″
-
- GROUND PRESSURE
- 7.68 psi
Swing Mechanism
-
- SWING PERFORMANCE: MAX SWING SPEED (AT EFFICIENCY)
- 9.3 rpm
Travel System/Drive Mechanism
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – LOW (XXX/)
- 2.11 mph
-
- TRAVEL PERFORMANCE: TRAVELING SPEED – HIGH (/XXX)
- 3.48 mph
-
- TRAVEL PERFORMANCE: GRADEABILITY
- 35 ° @ 70 %
Weights
-
- OPERATING WEIGHT
- 82416 lb
-
- STANDARD BOOM LENGTH
- 21′ 3″
-
- STANDARD ARM LENGTH
- 10′ 6″
-
- STANDARD BUCKET SIZE
- 1.95 yd³
-
- SHOE WIDTH
- 2′ 7″
Dimensions
-
- SHIPPING LENGTH (WITHOUT ATTACHMENT)
- 37′ 1″
-
- SHIPPING WIDTH (STANDARD)
- 11′ 5″
Working Range
-
- MAX DIGGING REACH (GROUND)
- 35′ 11″
-
- MAX DIGGING HEIGHT
- 33′ 10″
-
- MAX DIGGING DEPTH
- 24′ 8″
-
- MAX LOADING HEIGHT
- 23′ 6″
Digging Force (ISO)
-
- ARM DIGGING FORCE – PRESSURE UP
- 41590 lbf
-
- BUCKET DIGGING FORCE – PRESSURE UP
- 57101 lbf
-
- ARM DIGGING FORCE – NORMAL
- 39342 lbf
Refill Capacities
-
- FUEL TANK
- 158.5 gal
-
- HYDRAULIC SYSTEM
- 100.39 gal
-
- ENGINE COOLANT
- 14.82 gal
-
- ENGINE OIL
- 11.1 gal
-
- HYDRAULIC TANK
- 64.19 gal
Environment
-
- NOISE LEVEL: GUARANTEED SOUND POWER LEVEL
- 105 dBA
-
- NOISE LEVEL: OPERATOR
- 71 dBA
