PERFORMANCE
| Travel Speed | 3.1 mph (5 kph) / 1.7 mph (2.7 kph) |
| Drawbar Pulling Force | 17,200 lbf (77 kN) |
WEIGHT
| Operating Weight | 20,100 lbs (9,120 kg) |
ENGINE
| Model | Yanmar 4 TNV 98 CT |
| Power Output | 72 hp (53.7 kW) 70 hp (52.3 kW) |
| Max. Torque | 216 lbf (293 Nm) |
| Displacement | 202.5 in³ (3.318 ltr) |
| Fuel Tank | 31.7 gallons (US) (120 ltr) |
HYDRAULIC SYSTEM
| Pump | 2 Variable axial piston + Gear |
| Dozer Blade | Blade Height: 18″ (460 mm) Blade Width: 8′ (2,450 mm) Max. Raise Height: 20″ (500 mm) Dig Depth: 20″ (500 mm) |
